Ortofon TA-110 9" static-balance tonearm

TA-110 has gone to the next level by reducing unwanted vibrations in the tonearm. Ortofon's material know-how is the first area of the Ortofon technology that was applied when developing the TA-110. As a specialist in technical rubber, Ortofon used one of its special rubber compounds when creating the specially shaped rubber with high vibration dampening properties. The rubber pieces are produced at the Ortofon technical rubber facilities in Nakskov.

The second area of Ortofon technology is the extensive knowledge of vibration properties and characteristics. Ortofon has acquired this know-how via the developement of Bone Conductors for hearing aid industry. By using this knowledge and the related computer programs that simulated vibration in different shapes and materials, Ortofon came up with an optimized TA-110.

Features:


Effective mass without headshell: 3.5 g
Mass of supplied headshell: 15.5 g
Effective armlength (distance between the stylus and pivot point): 231.0 mm
Mounting distance (distance between the pivot point and turntable center): 213.0 mm
Offset angle: 23.9 degrees
Overhang: 18.0 mm
Tracking force adjusting range direct reading: 0-3 g
Tracking force adjusting range with extra mass ring mounted: 0-4 g
Height adjustment range: 35-55 mm
Diameter of the armbase mounting hole: 19-20 mm
Diameter of the center shaft of tonearm: 18.0 mm
Inner null point: 66 mm
Outer null point: 120.9 mm
Counterweight for cartridge + headshell mass between 21 and 28 g included
Headshell LH-2000E included, weight: 15.5 g
TA-110 total weight including headshell: 470 g
Set of tonearm cables 6NX-TSW-1010 included
Extra mass ring for heavier cartridges included, weight 45 g


Ortofon RS-212D 9" dynamic-balance tonearm

The Ortofon RS-212D tonearm takes analog sound reproduction to a higher level with highly configurable VTF options and a dynamic balance system for increased stability when tracking warps and other anomalies.

The RS D-Series tonearms can be used for a wide array of cartridges, feature anti-skating control.

Features:

Effective mass (without headshell) - 3.5 g
Effective length (distance between the stylus and pivot point) - 231mm
Mounting distance between the pivot point and turntable center) - 216mm
Offset angle - 22 degrees
Overhang - 15mm
Inner null point - 58,5 mm
Outer null point - 114,5 mm
Tracking force adjusting range (direct reading) - 0 - 5 g

Height adjustment range - 42 mm - 57 mm
Diameter of the armbase mounting hole - 34 mm - 36 mm
Diameter of the center shaf - 16 mm
Fixing holes PCD - dia. 50 mm
Size/Thread - dia. 3.2 mm (dia. 3mm x 20mm and dia. 3 mm wood screw)
Digital scale DS-1 included
Headhell SH-1 included


Ortofon AS-309S 12" static-balance tonearm

Ortofon AS-309S 12 inch static-balance tonearm features high quality materials and construction, combined with a nod to analog’s past, for precise sound reproduction combined with a modern-vintage aesthetic.
AS series tonearms can be used for a wide array of cartridges and feature anti-skating control. SPU cartridges require an additional counterweight.

Features:

Effective mass (without headshell) - 4.0 g
Effective length (distance between the stylus and pivot point) - 329mm
Mounting distance between the pivot point and turntable center - 314mm
Offset angle - 19 degrees
Overhang - 15mm
Tracking force adjusting range ( direct reading) - 0 to 3g
Height adjustment range - 35mm to 55mm
Diameter of the armbase mounting hole - 19mm to 20mm
Diameter of center shaft - 18mm


Ortofon RS-309D 12" dynamic-balance tonearm

RS-309D 12 inch Ortofon’s D series tonearm takes analog sound reproduction to a higher level with highly configurable VTF options and a dynamic balance system for increased stability when tracking warps and other anomalies.

D series tonearms can be used for a wide array of cartridges, feature anti-skating control.

Features:

Dynamic balance graduated vertical tracking force (VTF) control through a new spring design
The new short wire spring, housed in the pivot case, eliminates unwanted vibrations in the tone arm
VTF in the range 0-5 grams can be precisely adjusted by means of the supplied digital force gauge
Anti-skate control adjusted by calibrated dial in the range 0-5 gram
Tone arm height, and thereby VTA, is easy adjustable on the tonearm base.
Detachable head shell and tone arm cable, with standard SME-type connectors

Ikeda Sound Labs IT-407

Isamu Ikeda’s passion for the perfect analog sound began in the 1940’s when, being dissatisfied with the production at a previous audio company, Mr. Ikeda decided to form his own company – the world famous Fidelity Research Inc. Its products have been welcomed by audiophiles and music fans the world over, including the Imperial Household Agency and the Imperial Family. By the time the company released such systems as the FR-7 and FR-64s in 1978, it had grown to be a world-class audio manufacturer, developing the world's first air-core quadropole structure for FR-7. That passion continues today and is available in the United States….

About Ikeda Sound labs from audionautes.com…..

"Nevertheless, Ikeda's enthusiasm for the revival of analogue records continued unabated. In the same year (2000), he established Ikeda Sound Laboratories Company. For Ikeda, this company was a place where he was able to do things that had been impossible under mass production at Fidelity Research, that is, enhancing the precision of manufacturing, pursuing handmade production and experimenting with new ideas freely. Of course, all the products were designed, built and inspected by Isamu Ikeda himself. He also accomplished such feats as realizing air-core structure and developing the world's first MC cartridge without a cantilever, both of which had been his long-sought goals. As cutting heads used in manufacturing of analogue records have no cantilevers, he thought a MC cartridge without a cantilever could be created. Ikeda is a perfectionist. All Ikeda Labs. products, including those sold overseas, are repaired by Ikeda himself in Japan.

Download The IT-407 Spec sheet
